SGC Seed Storage Chamber
SGC Seed Storage Chamber

SGC Seed Storage Chamber

The Weiss Technik SGC 120 Seed Storage Chamber is perfect for simulating the cool, dry conditions used for long-term seed storage. The SGC 120 comes with an air drying system to remove humidity to a level of 15%rh at 4°C. It combines user-friendliness and cost-effectiveness with unequalled durability and reliability.
  • Growing area of 6.8m2
  • 10 shelves
  • Air drying system to remove humidity to 15%rh at 4°C
  • Suitable for medium and long-term collections

Specifications

Chamber size
  • Internal: 1310mm (w) x 675mm (d) x 1410mm (h)
  • External: 1440mm (w) x 810mm (d) x 1975mm (h)
  • Volume: 1200 liters nominal
Temperature range
  • +4°C
Temperature stability
  • +/-0.3°C
Humidity (optional)
  • 60%RH to 80%RH
Standard shelving (additional shelving available)
  • 5 levels of wire shelves

Shelving & lighting configurations

One shelf:
  • 12 x 36W fluorescent tubes per shelf
  • Max intensity approx. 620 µmol m-2 s-1 @ 150mm below tube @ 25°C
  • Max height between shelves 1275mm
Three shelves:
  • 4 x 36W fluorescent tubes per shelf
  • Max intensity approx. 170 µmol m-2 s-1@ 150mm below tube @ 25°C
  • Max height between shelves 400mm
Four shelves:
  • 3 x 36W fluorescent tubes per shelf
  • Max intensity approx. 140 µmol m-2 s-1@ 150mm below tube @ 25°C
  • Max height between shelves 250mm
Five shelves:
  • 2 x 36W fluorescent tubes per shelf
  • Max intensity approx. 100 µmol m-2 s-1@ 150mm below tube @ 25°C
  • Max height between shelves 200mm
