Description

The Weiss Technik SGC 120 Seed Storage Chamber is perfect for simulating the cool, dry conditions used for long-term seed storage. The SGC 120 comes with an air drying system to remove humidity to a level of 15%rh at 4°C. It combines user-friendliness and cost-effectiveness with unequalled durability and reliability.

Product Features

  • Growing area of 6.8m2
  • 10 shelves
  • Air drying system to remove humidity to 15%rh at 4°C
  • Suitable for medium and long-term collections

Specifications

Chamber size

  • Internal: 1310mm (w) x 675mm (d) x 1410mm (h)
  • External: 1440mm (w) x 810mm (d) x 1975mm (h)
  • Volume: 1200 liters nominal

Temperature range

  • +4°C

Temperature stability

  • +/-0.3°C

Humidity (optional)

  • 60%RH to 80%RH

Standard shelving (additional shelving available)

  • 5 levels of wire shelves

Shelving & lighting configurations

One shelf:

  • 12 x 36W fluorescent tubes per shelf
  • Max intensity approx. 620 µmol m-2 s-1 @ 150mm below tube @ 25°C
  • Max height between shelves 1275mm

Three shelves:

  • 4 x 36W fluorescent tubes per shelf
  • Max intensity approx. 170 µmol m-2 s-1@ 150mm below tube @ 25°C
  • Max height between shelves 400mm

Four shelves:

  • 3 x 36W fluorescent tubes per shelf
  • Max intensity approx. 140 µmol m-2 s-1@ 150mm below tube @ 25°C
  • Max height between shelves 250mm

Five shelves:

  • 2 x 36W fluorescent tubes per shelf
  • Max intensity approx. 100 µmol m-2 s-1@ 150mm below tube @ 25°C
  • Max height between shelves 200mm
